GE Dash 4000 Service Manual

Equipment overview: Components
2000966-542D Dash 3000/4000/5000 2-11
An optional remote display can be connected to the system for viewing on
a larger monitor, or in a separate room. The remote display requires:
 Dash Port 2 docking station,
 Dash 3000/4000 patient monitor software version 5 through version
7.1 with Dash Port 2 software version 2.0, or
 Dash 3000/4000/5000 patient monitor software version 7.2 or later
with Dash Port 2 software version 2.1 or later, and
 Must be within 150 feet of the Dash patient monitor.
ICG module
The ICG module (impedance cardiography) measures and processes
patient hemodynamic data.
BISx
Available in software version 6 or later, BISx measures the effect of
anesthetics and sedatives on the brain.
823B
825A
935A

GE Dash 4000 Specifications

General

Resolution	640 x 480 pixels
Power Supply	100-240 VAC, 50/60 Hz
ECG	3/5/12-lead
IBP	Up to 4 channels
Battery Backup	Yes
Certifications	CE, UL, CSA
Parameters Monitored	ECG, SpO2, NIBP, IBP, Temperature, Respiration, Cardiac Output
Connectivity	Ethernet, USB, Serial
Display Type	TFT LCD
Recorder	Integrated thermal printer
Battery Type	Lithium-ion
Operating Temperature	0 to 40°C
Storage Temperature	-20 to 60°C
Humidity Range	15% to 95% non-condensing
Display Size	10.4 inches
Cardiac Output	Available
