5
Loosen and remove the lens hood, then place the lens cap over the lens.
Lens hood
Lens cap
6
Disconnect the lens cable connector by rotating the knurling ring.
Connector of the lens cable
Knurling ring
7
Turn the lens slightly to the left and loosen it while pushing the lens release lever.
Lens release lever
20 ImageQuant LAS 4000 User Manual 28-9607-42 AB
3 Exchanging accessory parts
3.2 Installing or exchanging the lens
3.2.1 Removing the LAS High Sens. lens
