LPS-O Line Protection System GE Power Management
2.5 REFERENCE TABLES 2 CALCULATION OF SETTINGS
2
OUTPUTS
1601
T1 T1 Contract
0 to 256 step 1
†
0 to 256 step 1
†
33
‡
1602 T2 T2 Contact
0 to 256 step 1
†
0 to 256 step 1
†
33
‡
1603 T3 T3 Contact
0 to 256 step 1
†
0 to 256 step 1
†
33
‡
1604 T4 T4 Contact
0 to 256 step 1
†
0 to 256 step 1
†
33
‡
1605 T5 T5 Contact
0 to 256 step 1
†
0 to 256 step 1
†
0
‡
1606 T6 T6 Contact
0 to 256 step 1
†
0 to 256 step 1
†
0
‡
1607 A1
(configurable)
A1 Contact
0 to 256 step 1
†
0 to 256 step 1
†
58
‡
1608 A2
(configurable)
A2 Contact
0 to 256 step 1
†
0 to 256 step 1
†
59
‡
1609 A3
(configurable)
A3 Contact
0 to 256 step 1
†
0 to 256 step 1
†
33
‡
1610 A4
(configurable)
A4 Contact
0 to 256 step 1
†
0 to 256 step 1
†
33
‡
1611 A5
(configurable)
A5 Contact
0 to 256 step 1
†
0 to 256 step 1
†
37
‡
1612 A6
(configurable)
A6 Contact
0 to 256 step 1
†
0 to 256 step 1
†
37
‡
1613 A7
(configurable)
A7 Contact
0 to 256 step 1
†
0 to 256 step 1
†
38
‡
1614 A8
(configurable)
A8 Contact
0 to 256 step 1
†
0 to 256 step 1
†
45
‡
1615 A9
(configurable)
A9 Contact
0 to 256 step 1
†
0 to 256 step 1
†
77
‡
1616 A10
(configurable)
A10 Contact
0 to 256 step 1
†
0 to 256 step 1
†
132
‡
1617 A11
(configurable)
A11 Contact
0 to 256 step 1
†
0 to 256 step 1
†
120
‡
1618 A12
(configurable)
A12 Contact
0 to 256 step 1
†
0 to 256 step 1
†
121
‡
1619 C1
(configurable)
C1 Contact
0 to 256 step 1
†
0 to 256 step 1
†
52
‡
1620 C2
(configurable)
C2 Contact
0 to 256 step 1
†
0 to 256 step 1
†
115
‡
Table 2–7: PROTECTION SETTINGS GUIDE (Sheet 6 of 7)
No.
Mnemonic
Description Range (5A) Range (1A) Default
see TABLE NOTES on page 2–43 for footnote explanation
