Ethernet Port
IRIG-B Time In
Display Port
Analog DC Input (AI)
Binary Input (DI)
Binary Output (DO)
Hardware overview
MCP is the Multifunction Controller Platform family of Substation Gateways by GE Grid Solutions.
G100 is the smaller member of the family, together with G500.
G100 is based on Intel® Apollo Lake SOC, with Intel Atom X5-E3930 1.3GHz Processor to provide quality
performance with low power consumption and wide operating temperature. It has 8 Gigabytes of SoDIMM 204
pin DDR3L memory.
The G100 is distinguished by the noticeable lack of a hard drive and fan, employing instead the rugged and
reliable Solid State Drive (SSD) mass storage and engineered heat sink.
The G100 supports various communication media types through a choice of input/output (I/0):
• Serial: 4 factory installed ports, RS-232 and RS-485 configurable, accessible via individual RJ45
connectors.
• Ethernet: 2 factory installed RJ45 Ethernet interfaces with to 2 additional SFP cages..
• D.20 Link HDLC ports: A dual channel PCIe card for communication with up to 60 – D.20 Peripherals
channel, including redundant D.20 link configuration.
• IRIG-B TTL input
• Local General Purpose IO (GPIO) interface, providing:
