Installation of optional D.20 HDLC Card
The optional D.20 HDLC card can be ordered already installed with the unit at factory time, or can be installed
later, as follows.
Before you open the G100 chassis to install the D.20 HDLC Card, read and follow the guidelines and
instructions in Electro Static Discharge - ESD
1. To install the D.20 HDLC card, flip over the system and loosen and remove the eight screws indicated
below so that the chassis cover can be removed.
2. Place the card into the system as shown in the picture.
