18 994-0155-1.00-1 GE Information
Order Code
Table 3: G100 Order Code
To know the Order Code of your G100, run mcpsi command through the Shell access utility (see Quick Start
Guide and Software Manual for more details).
“As-Built” is the order code at factory build time.
“As-Is” is the order code at the time when the user runs the command.
In the example below, after the unit was built in the factory, there were added and configured two Fiber Optic
SFP (F) and a D.20 PCIe card (D).
admin@G100:~$ mcpsi
Retrieving the GE Multilin MCP system information, please wait ...
===============================================================================
GE Multilin MCP System Information
===============================================================================
Model Number:
As-Built: G100-AAL-DA-4TTUU-UUU-B2022-UU
As-Is : G100-AAL-DA-4TTFF-DUU-B2022-UU
Please visit the online store for application licenses ordering codes. For latest configuration and options, please
visit the online store and search for G100:
https://store.gegridsolutions.com/Home.aspx
A A L - D A - 4 T T * * - * U U - * * * * * - UU Description
CPU and Memory A 1.3GHz 2-core CPU, 8GB RAM
Storage A 16GB Solid State Drive
Power Supply L
12–54VDC (10.8-59.4 absolute min/max)
Digital Input / Output D 8x DI 12/24/48Vdc, 5mA & 4x DO 60Vdc (max.), 1A
DC Analog Inputs A 4x ±5Vdc/ 20mA analog input
Serial Ports 4 4x Serial Ports, RS-232/ RS-485 independently configurable and isolated
Ethernet Interface - Built In T
T 10/100/1000BASE-TX (RJ45 copper)
Ethernet Interface - SFP type C C 100BASE-TX (RJ45 copper) [0123-0004]
T T 1000BASE-TX (RJ45 copper) [580-3786]
F F 100BASE-FX (LC fiber multimode) [580-3784]
S S 1000BASE-SX (LC fiber multimode) [580-3785]
L L 1000BASE-LX (LC fiber single-mode) [580-3787]
PCIe Expansion Module D 2x D.20 Link Ports [528-1007LF]
Latest Firmware Version
(Default)
B2 v2.2 firmware version
Licenses xxx SW Licenses (ARRM, IEC61850-Client, LogicLinx IEC 61131-3)
