G100 Instruction Manual
GE Information
994-0155-1.00-1
45
PCOMMON
306 PCOMMON v3.06 All
305 PCOMMON v3.05 All
301 PCOMMON v3.01 All
300 PCOMMON v3.00 All
Table 13: D20C Combination Input/Output Module Compatibility
Component GE Item # Description
Compatible
release
Date of
release
WESDAC 504-0002 WESDAC D20C+ REL 20-higher
September
1996
WESDAC 504-0003 WESDAC D20CHV All
WESTERM 517-0180 WESTERM D20 CD All
Redundant D.20
LAN
540-0209
WESDAC D20C D.20/WESMAINT
I/F
All
PCOMMON
305 PCOMMON v3.05 All
300 PCOMMON v3.00 All
Table 14: Repeater/Splitter Compatibility
Component GE Item # Description
Compatible
release
Date of
release
REPEATER 520-0117
D.20 COMMUNICATION
INTERFACE
REL 13 -higher April 1999
SPLITTER 520-0118 D.20 FIBER OPTIC SPLITTER 4-WA REL 11 -higher April 1999
GFO 520-0148 WESDAC D.20 RS485/GFO I/F 48V REL 09 -higher
December
1994
D.20 Connection topologies
The D.20 HDLC PCIe card supports the below D.20 topologies:
• Single D.20 terminated, single link
• Dual D.20 link terminated
• Single D.20 link, redundant LAN
• Redundant D.20 link, redundant LAN
Single D.20 terminated, single link
Figure 4: Single D.20 terminated, single link - Topology
