x/EN ST/Na7
-
MiCOM P74
Menu Text Default Setting
Setting Range
Step Size
Min. Max.
FUNCTION KEYS
Fn. Key 2 to 10 Mode
Toggled Toggled, Normal
Sets the function key in toggle or normal mode (see “Fn. Key 1 mode”)
Fn. Key 2 to 10 Label
Function Key 2 to 10
Allows the text of the function key to be changed.
1.3.12 “IED Configurator” column (P741 / P743 only)
The contents of the IED CONFIGURATOR column (for IEC 61850 configuration) are mostly
data cells, displayed for information but not editable. In order to edit the configuration, it is
necessary to use the IED (Intelligent Electronic Device) configurator tool within S1.
Menu Text Default Setting
Setting Range
Step Size
Min. Max.
IED CONFIGURATOR
Switch Conf.Bank No Action No Action, Switch Banks
Setting which allows the user to switch between
the current configuration, held in the
Active Memory Bank (and partly displayed below), to the configuration sent to and held in
the Inactive Memory Bank.
Restore MCL No action No action / Restore MCL
Used to restore data from MCL binary file. MCL (MiCOM Configuration Language) files are
ALSTOM Grid-specific, containing a single devices IEC61850 configuration information,
and used for transferring data to/from the IED.
Active Conf.Name Data
The name of the configuration in the Active Memory Bank, usually taken from the SCL file.
Active Conf.Rev Data
Configuration Revision number of the Active Memory Bank, used for version management.
Inact.Conf.Name Data
The name of the configuration in the Inactive Memory Bank, usually taken from the SCL
file.
Inact.Conf.Rev Data
Configuration Revision number of the Inactive Memory Bank, used for version
management.
IP PARAMETERS
IP Address Data
Displays the unique network IP address that identifies the relay.
Subnet Mask Data
Displays the sub-network that the relay is connected to.
Gateway Data
Displays the IP address of the gateway (proxy) that the relay is connected to.
SNTP PARAMETERS
SNTP Server 1 Data
Displays the IP address of the primary SNTP server.
