GE P741

P74x/EN CM/Na7
Commissioning
(CM) 10-46
MiCOM P741, P742, P743
CM
11. SETTING RECORD
11.1 Central Unit: P741
Date: Engineer:
Station: Circuit:
System Frequency:
Front Plate Information
Central Unit type: P741
Model Number
Serial Number
Rated Current In
Auxiliary Voltage Vx
Setting Groups Used
Group 1

Yes

No
Group 2

Yes

No
Group 3

Yes

No
Group 4

Yes

No
11.1.1 Relays Setting configuration
0000 SYSTEM DATA
Language

English,

Francais,

Deutsch,

Espanol.
Description
Plant Reference
Model Number
Serial Number
Frequency

50hz

60Hz
Comms Level
Relay Address
Plant Status
Control Status
Active Group
Software Ref.1
Software Ref.2
Not displayed

Opto I/P Status
Relay O/P Status
Alarm Status
Relay O/P Status 1
Relay O/P Status 2
Alarm Status 1
