P74x/EN PL/N
1, P742, P743
(PL) 7-
1.5 Toolbar and commands
There are a number of toolbars available for easy navigation and editing of PSL.
1.5.1 Standard tools
• For file management and printing.
1.5.2 Alignment tools
• To snap logic elements into horizontally or vertically aligned groupings.
1.5.3 Drawing Tools
• To add text comments and other annotations, for easier reading of PSL schemes.
1.5.4 Nudge tools
• To move logic elements.
1.5.5 Rotation tools
• Tools to spin, mirror and flip.
1.5.6 Structure tools
• To change the stacking order of logic components.
1.5.7 Zoom and pan tools
• For scaling the displayed screen size, viewing the entire PSL, or zooming to a selection.
1.5.8 Logic symbols
This toolbar provides icons to place each type of logic element into the scheme diagram. Not
all elements are available in all devices. Icons will only be displayed for those elements
available in the selected device.
