GE P741

Settings
P74x/EN ST/N
a7
MiCOM P74
1, P742, P743
(ST) 4-
9
ST
MENU TEXT Default Setting Available Settings
CONFIGURATION
Copy to No Operation No Operation / Group 1 / Group 2
Group 3 / Group 4
Allows displayed settings to be copied to a selected setting group (ready to paste).
Setting Group 1 Enabled Enabled/Disabled
If the setting group is disabled from the configuration, then all associated settings and
signals are hidden, with the exception of this setting (paste).
Setting Group 2 Disabled Enabled/Disabled
Setting Group 3 Disabled Enabled/Disabled
Setting Group 4 Disabled Enabled/Disabled
Dead Zone Prot Enabled Enabled/Disabled
To enable (activate) or disable (turn off) the Dead Zone Protection function.
BB Trip Confirm Disabled Enabled/Disabled
To enable (activate) o
r disable (turn off) the Busbar Trip order confirmation on an
overcurrent function to allow to trip the breaker.
Overcurrent Prot Disabled Enabled/Disabled
To enable (activate) or disable (turn off) the Phase Overcurrent Protection function.
ANSI 50P/51.
Earth Fault Prot Disabled Enabled/Disabled
To enable (activate) or disable (turn off) the Earth Overcurrent Protection function.
ANSI 50N/51N.
CB Fail & I< Disabled Enabled/Disabled
To enable (activate) or disable (turn off) the Circuit Breaker Fail Protection functions.
ANSI 50BF.
Input Labels Visible Visible/Invisible
Sets the Input Labels menu visible further on in the relay settings menu.
Output Labels Visible Visible/Invisible
Sets the Output Labels menu visible further on in the relay settings menu.
CT & VT Ratios Visible Visible/Invisible
Sets the Current & Voltage Transformer Ratios menu visible further on in the relay settings
menu.
Recorder Control Visible Visible/Invisible
Sets the Record Control menu visible further on in the relay settings menu.
Disturb Recorder Visible Visible/Invisible
Sets the Disturbance Recorder menu visible further on in the relay settings menu.
Measure't Setup Visible Visible/Invisible
Sets the Measurement Setup menu visible further on in the relay settings menu.
Comms Settings Invisible Visible/Invisible
Sets the Communications Settings menu visible further on in the relay settings menu.
Commission Tests Visible Visible/Invisible
Sets the Commissioning Tests menu visible further on in the relay settings menu.
