D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
4-20 Section 4-3 - Functional Checks
PRELIMINARY
4-3-6 Probe/Connectors Check
NOTE: Probes can be connected at any time, whether the unit is ON or OFF
Related information:
• Electrical Safety Tests on page 10 - 15
Take the following precautions with the probe cables:
• Keep away from the wheels.
• Do not bend.
• Do not cross cables between probes.
Table 4-19 Probe and Connectors Checks
Step Task Expected Result(s)
1
Press Probe on the Operator Panel. A list of the connected probes will pop
up on the screen.
2
Select the desired probe. An application menu for the desired
probe is listed on the screen.
3
• Browse to the desired application.
• Press Select to launch the application.
• To change application without changing the current
probe, press Appl. on the Operator Panel.
The selected application starts.
4
Verify no missing channels. All channels are functioning.
5
Verify there's no EMI/RFI or artifacts specific to the
probe.
No EMI/RFI or artifacts.
6
Check the probe in each active connector slot. It will display pictorial data each time.
7
Do a leakage test on the probe. It passes the test.
8
Repeat this procedure for all available probes.
