D
IRECTION 5771498-100, REVISION 5 VENUE™ SERVICE MANUAL
Chapter 5 - Venue™Components and Function (Theory) 5-25
PRELIMINARY
5-9-4 Back End Interface (BIB) Board
The purpose of the Back End Board (BIB) module is to unify communications from all the boards in the
system and redirect them to their relevant destinations.
The Back End Board (BIB) module, responsible for the scanner Interfaces, comprises three main
Interfaces:
• Back End (mITX standard)- via the Docking Interface
• Csound Front End (CFE) Board
• Main Power Board (MPB)
5-9-5 Solid State Hard Drive
The Hard Disk is the main storage device of the Venue™ ultrasound unit. The Hard Disk, which is
controlled by the CPU via signals from the SATA Bus.

GE Venue R1 Specifications

General

Type	Ultrasound System
Imaging Modes	Color Doppler
Connectivity	DICOM, USB, Ethernet
Power Supply	100-240 VAC, 50/60 Hz
Ports	Ethernet, USB
Supported Probes	Linear, Convex, Phased Array
