IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
Chapter 3 - System Setup 3-3
PRELIMINARY
6
3-2-3 Safety Reminders
NOTE: The Venue™ User Manual should be fully read and understood before operating the unit. Keep
the manual near the unit for reference.
Table 3-9 Venue™ System Acclimation Time
°C
-40 -35 -30 -25 -20 -15 -10 -5 0 5 10 35 40 45 50 55 60
°F
-40 -31 -22 -13 -4 5 14 23 32 41 50 95 104 113 122 131 140
Hrs
20 18 16 14 12 10 8 4 2 0 0 0 2 4 6 8
WHEN USING ANY TEST INSTRUMENT THAT IS CAPABLE OF OPENING THE
AC GROUND LINE (I.E., METER’S GROUND SWITCH IS OPEN), DO NOT TOUCH
THE UNIT!
TWO PEOPLE ARE REQUIRED TO UNPACK THE SYSTEM AS IT IS HEAVY.
TWO PEOPLE ARE ALWAYS REQUIRED WHENEVER A PART WEIGHING 16KG (35 LB.)
OR MORE MUST BE LIFTED.
TO PREVENT ELECTRICAL SHOCK, CONNECT THE UNIT TO A PROPERLY GROUNDED
POWER OUTLET.
DO NOT USE A THREE-PRONG TO TWO-PRONG ADAPTER, AS THIS DEFEATS SAFETY
GROUNDING.
DO NOT WEAR THE ESD WRIST STRAP WHEN YOU WORK ON LIVE CIRCUITS WHERE MORE
THAN 30 V PEAK IS PRESENT.
DO NOT OPERATE THE UNIT UNLESS ALL BOARD COVERS AND FRAME PANELS ARE
SECURELY IN PLACE, TO ENSURE OPTIMAL SYSTEM PERFORMANCE AND COOLING.
(WHEN COVERS ARE REMOVED, EMI MAY BE PRESENT).
ACOUSTIC OUTPUT HAZARD
ALTHOUGH THE ULTRASOUND ENERGY TRANSMITTED FROM THE Venue™
PORTABLE ULTRASOUND SCANNER IS WITHIN AIUM/NEMA STANDARDS AND FDA
LIMITATIONS, AVOID UNNECESSARY EXPOSURE. ULTRASOUND ENERGY CAN
PRODUCE HEAT AND MECHANICAL DAMAGE
.
