D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
Chapter 1 - Introduction 1-27
PRELIMINARY
1-7-3 Venue™ External Labels Location
In addition to the labels described in the previous section, an additional label may be found on the
Venue™ ultrasound unit, as described in the following section.
Figure 1-1 Venue™ System - Configuration of Main Hardware Components
