Section 8-4
System Modules- Replacement Procedures
8-4-1 Base Module Replacement Procedure
8-4-1-1 Tools
LOCTITE® 243™
Allen key 4mm.
8-4-1-2 Time Required
10 min
8-4-1-3 Preparations
1.) Shut down the Venue™ ultrasound unit, as described in Power Shut Down .
2.) Make sure the On/Off power switch is set to Off.
3.) Make sure the system is standing securely on a level surface, with the wheels in the locked position.
8-4-1-4 Base Module Removal Procedure
1.) Remove all accessories.
2.) Remove the cockpit (monitor).
3.) Remove the following covers: Lower Front eTower, RS Probe cover, Right Side and Left Side
eTower covers, and Front Base Cover
4.) Position the system on its side to gain access to the system base.
5.) Unscrew the four base mounting screws.
Refer to Table 9-6 on page 9-5.
• Accessories - Replacement Procedures
• Cockpit (Monitor) Removal Procedure
• Lower Front eTower Cover Removal Procedure
• RS Probe Cover Removal Procedure
• Left Side eTower Cover Removal Procedure
• Right Side eTower Cover Removal Procedure
• Front Base Cover Removal Procedure
