D
IRECTION 5771498-100, REVISION 5 VENUE™ SERVICE MANUAL
5-12 Section 5-6 - Cockpit (Monitor) Module
PRELIMINARY
5-6-1-2 Power On/Off Touch Button
The On/Off touch button is located in the upper right corner of the cockpit (monitor) to prevent accidental
activation.
Figure 5-9 Power On/Off Touch button
The system On/Off button has two colors for power status indication:
• Green: indicates system power on
• Orange: indicates system power off.
The On/Off touch button is sensitive to:
• A bare finger
• A Latex gloved hand
• A Latex gloved hand with ultrasound gel.
5-6-1-3 Sleep Mode Indicator
The Sleep Mode indicator is located in the upper left corner of the cockpit (monitor) to prevent accidental
activation.
Figure 5-10 Sleep Mode Indicator
The system Sleep Mode button has one color for sleep status indication:
• No color: Sleep mode is not activated
• Orange: Sleep mode is activated.
The Sleep Mode touch button is sensitive to:
• A bare finger
• A Latex gloved hand
• A Latex gloved hand with ultrasound gel.
