IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL

Chapter 3 - System Setup 3-31

PRELIMINARY

8.) On the InSite tab, define the required settings and tap Submit Changes. Make sure you fill all

mandatory fields (highlighted in bold). Then, proceed to the next tab.

Figure 3-33 Venue™ Installation Wizard - InSite Tab
