Basic OperationBasic Operation
The Web Interface
► Tabs and Sub-tabs
The web interface is organized into tabs, in the top-portion of the screen. Clicking on
a tab will display a different screen.
The Setup and Manage EDID tab have their own set of tabs, which we will refer to as
“sub-tabs”, as shown below.
► Buttons
Several screen contain buttons which allow the selection of a particular mode or
setting. Click the button for the desired setting. Buttons that are red represent
a setting that is “turned on”. If the button is pale-yellow, then the feature is “turned off”:
• Feature is “turned on”
• Feature is “turned off”
Screen sub-tab
Screen tab
Basic OperationBasic Operation
