page | 35
Basic Operation
4. Click the desired preset to edit.
5. The selected preset will be highlighted. In this example, we will select Preset 6.
6. Select the desired routing state for each input/output. See Routing Inputs and Mask-
ing Outputs (page 31), if necessary. The preset selections for the selected preset,
will be indicated by a green square, as shown below. Note that an output can also be
set to OFF.
7. To save the audio volume level for an output, click the check box, next to the volume
slider, as shown in the example below.
The Web Interface
