ADV100 • Functions description and parameters list 115
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.5 4508 ExtFltrestarttime ms UINT16 1000 120 30000 RW FVS
Setting of the time within which the ExternalFaultalarm must be reset in order to perform automatic restart.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.6 4510 ExtFltholdoff ms UINT16 0 0 10000 RW FVS
Setting of the delay between the signalling of the external fault alarm ExtFlt and enabling of the alarm. If an alarm
condition occurs, the drive will wait for the set time before blocking is enabled. If the alarm is removed within the set
time, the drive will not indicate any alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.7 4520 MotorOTsrc LINK 16 6000 0 16384 RW FVS
Selection of the origin (source) of the signal to be used for the motor overtemperature alarm MotorOT. The terminal
that can be used for this function can be selected from among those listed in the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.8 4522 MotorOTactivity ENUM Warning 0 4 RW FVS
Setting of the behaviour of the drive in case of a motor overtemperature alarm MotorOT. This alarm indicates that
the motor temperature is too high.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.9 4524 MotorOTrestart ENUM Disable 0 1 RW FVS
Enabling of automatic restart after the motor overtemperature alarm MotorOT.
0 Disable
1 Enable
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.10 4526 TMotorOTrestarttime ms UINT16 1000 120 30000 RW FVS
Setting of the time within which the MotorOvertemperaturealarm must be reset in order to perform automatic
restart.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.11 4528 MotorOTholdoff ms UINT16 1000 0 30000 RW FVS
Setting of the delay between the signalling of the motor overtemperature alarm MotorOT and enabling of the alarm.
If an alarm condition occurs, the drive will wait for the set time before enabling the alarm. If the alarm is removed
within the set time, the drive will not indicate any alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.12 4540 Overspeedthreshold rpm INT32 CALCI 0 CALCI RW FVS
Setting of the threshold above which the overspeed alarm Overspeed is enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.13 4542 Overspeedactivity ENUM Disable 0 4 RW FVS
Setting of the behaviour of the drive in case of a motor overspeed alarm Overspeed. This alarm indicates that the
motor speed has exceeded the threshold set in the Speedreftoplimand Speedrefbottomlim parameters in the
