ADV100 • Functions description and parameters list 125
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 11010 Refencesunit ENUM % 0 3 RWZ FVS
Parameter for selecting the unit of measure of the value to be controlled. It changes the unit of measure in param-
eters 11002 Setpointval, 11006 Feedbackval, 11012 Signalsfullscale and 11014 Signalsoffset.
0 %
1 m3/h
2 °C
3 bar
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 11012 Signalsfullscale FLOAT 100 RWZ FVS
Parameter for scaling the input reference and feedback. It must correspond to the maximum limit for the value to be
controlled.
For correct tuning, for example when a transducer is used to measure the feedback that supplies a 0-10V signal.
The recommended setting for this parameter is the physical value to which the 10V of the signal correspond. (e.g. 5
bar = 10V)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 11014 Signalsoffset FLOAT 0 RWZ FVS
Parameter for scaling the input reference and feedback. This must correspond to the minimum limit for the value to
be controlled.
For correct tuning, for example when a transducer is used to measure the feedback that supplies a 0-10V signal.
The recommended setting for this parameter is the physical value to which the 0V of the signal correspond.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 11016 StartPIDsel ENUM Mon ing an 1X 0 4484 RW FVS
Parameter for selecting the source of the command to enable the PID controller. If this command is not active when
the PID is enabled, the PID will be in the STOP condition, the PID controller will not function and the drive will be
disabled.
When DigitalParam [0] is selected the source of the Start PID command corresponds to the value set in parameter
11018 StartPID.
0 Digital Param
1110 Dig Inp E Mon
1210 Dig Input 1X
1212 Dig Input 2X
1214 Dig Input 3X
1216 Dig Input 4X
1218 Dig Input 5X
1220 Dig Input 6X
1222 Dig Input 7X
1224 Dig Input 8x
3702 PID Start mon
3704 FB level alarm
3706 Wait state mon
3708 Const pres mon
3710 Pad 6
3712 Pad 7
3714 Pad 8
3716 Pad 9
3718 Pad 10
3720 Pad 11
3722 Pad 12
3724 Pad 13
3726 Pad 14
3728 Pad 15
3730 Pad 16
4024 FieldbusM->S1
4034 FieldbusM->S2
