126 ADV100 • Functions description and parameters list
4044 FieldbusM->S3
4054 FieldbusM->S4
4064 FieldbusM->S5
4074 FieldbusM->S6
4084 FieldbusM->S7
4094 FieldbusM->S8
4104 FieldbusM->S9
4114 FieldbusM->S10
4124 FieldbusM->S11
4134 FieldbusM->S12
4144 FieldbusM->S13
4154 FieldbusM->S14
4164 FieldbusM->S15
4174 FieldbusM->S16
4454 Bit0 decompMon
4456 Bit1 decompMon
4458 Bit2 decompMon
4460 Bit3 decompMon
4462 Bit4 decompMon
4464 Bit5 decompMon
4466 Bit6 decompMon
4468 Bit7 decompMon
4470 Bit8 decompMon
4472 Bit9 decompMon
4474 Bit10decompMon
4476 Bit11decompMon
4478 Bit12decompMon
4480 Bit13decompMon
4482 Bit14decompMon
4484 Bit15decompMon
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 11018 StartPID ENUM Not Active 0 1 RW FVS
Parameter for selecting the source of the command to enable the PID controller. If this command is not active when
the PID is enabled, the PID will be in the STOP condition, the PID controller will not function and the drive will be
disabled.
When Digital Param is selected the source of the Start PID command corresponds to the value set in PAR 11018
StartPID.
0 Not Active
1 Active
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 12000 PidOutput rpm INT32 0 0 16384 R FVS
This variable displays the PID output: it can assume values of 0 to 16384 and if used as the drive speed reference
the value of 16384 corresponds to the value set in PAR 680 Fullscalespeed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 12004 PidState ENUM Disable 0 5 R FVS
This variable displays the current state of the PID controller.
0 Disable
1 PID
2 Stop
3 Alarm
4 Wait
5 Pressure const
If 0 (Disable) is displayed, parameter 11000 Setpointselhas been set to PID disabled.
If 1(PID) is displayed, the controller is functioning and the drive speed reference is therefore linked to the PID out-
