16 ADV100 • Functions description and parameters list
0 Easy
1 Expert
The Easy mode gives access to a list of parameters that can be used for rapid drive commissioning. This type of
conguration is suitable for the majority of applications.
Setting the parameter to Expert gives access to all the parameters in the rmware. This mode allows an extremely
high level of customization to be achieved in order to exploit the potential of the ADV100 to the full.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.4 556 Controlmodeselect ENUM Ramp 0 2 ERWZ F_S
Selection of the drive control mode.
0 Torque
1 Speed
2 Ramp
In torquecontrol(0-Torque)the reference and load of the motor determine its speed and direction of rotation.
Symmetrical torque limits can be set, for each direction of rotation and for motor/generator operation. This type of
control is only available in the FluxvectorCL control mode. In this mode the Ramp function is not used to generate
the drive speed reference so it can be used in stand-alone mode.
In speedcontrol(1-Speed) the reference arrives straight after the ramp circuit, enabling an extremely rapid re-
sponse to signal variations. This is ideal for applications that require a highly dynamic response. This type of control
is available in the FluxvectorOL and FluxvectorCL control modes. In this mode the Ramp function is not used to
generate the drive speed reference so it can be used in stand-alone mode.
In controlwithramp(2-Ramp) the speed reference is applied to the input of the “Ramp” block and is produced
by the “Rampref” block. This allows setting of both the acceleration/deceleration times and the ramp time (linear or
S-shaped with customizable jerks). This type of control is available in all control.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.5 558 Applicationselect ENUM None 0 2 ERWZ FVS
Selection of which IEC 61131-3-compliant application to make operational.
0 None
1 Application 1
2 Application 2
The drive is supplied already incorporating a number of applications developed in the IEC 61331-3 environment. To
use these, congure the desired application, run save parameter, switch the drive off and then on again.
NOTE! The LoadDefaultcommand (par. 580) does not modify this parameter
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.6 560 Mainsvoltage ENUM 400 V SIZE SIZE ERWZS FVS
Setting of the available mains voltage value in Volts. Detection of the undervoltage alarm refers to this value.
0 None
1 230 V
2 380 V
3 400 V
4 415 V
5 440 V
