24 ADV100 • Functions description and parameters list

When assigning the reference via terminals, signals with ±10V, 0 ...10V, 0... 20 mA and 4 ... 20 mA can be used.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

5.19 654 Speedrefinvertsrc LINK 16 6000 0 16384 ERWZ FVS

Selection of the origin (source) of the signal that inverts the speed reference output from the regulator. The terminal

that can be used for this function can be selected from among those listed in the “L_DIGSEL2” selection list.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

5.20 660 Speedref1mon rpm INT16 0 0 0 ER FVS

5.21 662 Speedref2mon rpm INT16 0 0 0 ER FVS

The value of the relative speed reference is displayed.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

5.22 670 Speedreftoplim rpm INT32 CALCI 0 CALCI ERWZ FVS

Setting of the upper speed reference limit. If the speed reference exceeds the limits, the motor speed remains at the

set limit value in any case. Speed limits cannot be more than 200% of the value set in the Fullscalespeed param-

eter (REFENCES menu par. 680).

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

5.23 672 Speedrefbottomlim rpm INT32 CALCI CALCI 0 ERWZ FVS

Setting of the lower speed reference limit. If the speed reference exceeds the limits, the motor speed remains at the

set limit value in any case. Speed limits cannot be more than 200% of the value set in the Fullscalespeed param-

eter (REFERENCES menu par. 680).

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

5.24 680 Fullscalespeed rpm INT16 CALCI 50 32000 RWZ FVS

Setting of the reference value for all speed percentage data (References, Speed adaptives ...) corresponding to 100

% of the actual speed. This parameter can only be changed with the inverter blocked (Enable drive = Disabled). The

recommended setting for the value of this parameter is the motor rated speed. If altered, the self-tuning procedure

should be repeated.

Fullscalespeed does not dene the maximum possible speed. In any case, the maximum speed percentage value

is ± 200 % of the Fullscalespeed value.
