50 ADV100 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.21 1050 FRreversemon BIT 16 0 0 1 ER FVS
The status of the Reverse output of the ForwardReverseControl(FRC) block is displayed.
0 No Reverse
1 Reverse
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.22 1052 FRcdmmon UINT16 0 0 0 ER FVS
The status of the commands of the ForwardReverseControl(FRC)block are displayed.
FR*stopsrc FRreversesrc FRforwardsrc FRcdmmon
0 0 0 0
0 0 1 1
0 1 0 2
0 1 1 3
1 0 0 4
1 0 1 5
1 1 0 6
1 1 1 7
