ADV100 • Functions description and parameters list 61
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.5 2008 Polepairs UINT16 SIZE 1 20 RWZS FVS
Motor pole pairs. The number of motor pole pairs is calculated using the motor plate data and applying the following
formula:
60 [s] x f [Hz]
P =
nN [rpm]
Where:
p = motor pole pairs
f = motor rated frequency (P. 2006)
nN = motor rated speed (P. 2004)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.6 2010 Ratedpower kW FLOAT SIZE 0.1 1500.0 RWZS FVS
Rated power of the motor at the rated voltage and frequency. This value represents the mechanical power produced
on the motor shaft.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.7 2012 Ratedpowerfactor FLOAT SIZE 0.6 0.95 RWZS FVS
Motor power factor, as indicated on the data plate (Cos j). This parameter is not always present on the motor data
plate: in that case use the default value present in the drive.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.8 2020 Takeparameters BIT 0 0 1 RWZ FVS
Saves the set motor data in the drive. This command must be supplied last after entering the appropriate values of
all the parameters listed above. This means calculating the normalization factors (a) and estimated values for the
motor parameters (b). The drive cannot be started until the Takeparameterscommand has been set.
Note ! This is not saved permanently. Use the “SaveParameters” command in the DRIVECONFIGmenu to save in the perma-
nent memory.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.9 2022 Autotunerotation BIT 0 0 1 RWZ FVS
Performs self-tuning in rotation: the motor must be uncoupled from the load or the transmission must not represent
more than 5% of the load. This procedure allows the greatest degree of accuracy in measuring the motor param-
eters. To execute the command you must rst open the hardware enabling contact between terminals 9 and 12. Next
set the Regulationmodeparameter to Autotune. If you are not already in Local mode, press the Local key (the
LOC
LED will light up) and close the hardware enabling contact again (terminals 9 and 12). Selt-tuning can now be
performed. At the end of the self-tuning procedure, open the contact between terminals 9 and 12 again and reset the
parameters that were modied.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.10 2024 Autotunestill BIT 0 0 1 RWZ FVS
Performs self-tuning with the motor coupled to the transmission. The self-tuning procedure may cause limited rota-
tion of the motor shaft. To perform self-tuning, follow the procedure described for the previous parameter.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.11 2026 Autotunemode ENUM Reduced 0 1 ERWZ FVS
Selection of the motor parameter self-tuning mode
0 Reduced
1 Extended
