62 ADV100 • Functions description and parameters list
If set to 0 all the motor parameters are measured except those relating to the non-linear saturation curve. Use this
mode to obtain a faster self-tuning procedure.
If set to 1 all the motor parameters are measured. Use this mode to obtain maximum efciency: this procedure may
take a few minutes.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.12 2028 Takestatus ENUM Required 0 0 R FVS
Indication of the status of parameter saving.
0 Required
1 Done
The parameter displays the Required message when the motor parameters that have been entered need to be
saved. When they have been saved the parameter indicates Done.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.13 2030 Autotunestatus ENUM Required 0 0 R FVS
Indication of the status of execution of motor parameter self-tuning.
0 Required
1 Done
The parameter displays the Required message when motor parameter self-tuning is required. When self-tuning is
complete the parameter indicates Done.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.14 2050 MeasuredRs ohm FLOAT CALCF 0.0005 200.0 ERWS FVS
Measured stator resistance value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.15 2052 MeasuredDTL V FLOAT 0.0 0.0 100.0 ERWS FVS
Measured value of dead time compensation.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.16 2054 MeasuredDTS V/A FLOAT 0.0 0.0 100.0 ERWS FVS
Measured compensation gradient value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.17 2056 MeasuredLsig mH FLOAT CALCF 0.1 200.0 ERWS FVS
Measured leakage inductance value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.18 2058 MeasuredImN A FLOAT CALCF 0.1 1500 .0
ERWS FVS
Measured rated magnetizing current value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.19 2060 MeasuredImX A FLOAT CALCF 0.0 0.0 ERWS FVS
Measured magnetizing current saturation value.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
16.20 2062 MeasuredFlxN Wb FLOAT CALCF 0.05 10.0 ERWS FVS
Measured rated ux value.
