Disk 4•27
○○○○○○○○○○○○○○○○○○○○○○
Disk 4•27
SCSI UTILITY
(Available only if the SCSI port has been ena-
bled by installing the optional SCSI kit).
This page offers a configuration of formatting
options for periferal SCSI devices, depending on
the current operating system running on your PS/
GPS. The following example shows one of the
possible configutations.
FAST ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a high speed method without check-
ing the medium for possible bad blocks.
ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a slower but optimsed method, check-
ing the medium for possible bad blocks. Any bad
blocks found will be masked with the resulting
reduction of the overall capacity of the disk.
ADDITIONAL DISK FUNCTIONS
This section explains the various options found
in the main Disk pages and in the File Selector,
some of which are permanent, others specific to
a particular command or disk page.
NEW FL. DISK (F5)
Updates the current directory after changing a
disk inserted in the drive, allowing the instrument
to recognize the disk change. Pressing the F5
Soft button opens the following dialog window:
You can also see the new directory by escaping
Disk mode the re-entring.
FREE MEMORY (F6)
This option displays the amount of memory re-
maining in the floppy disk, Hard disk, System-
RAM, Backed Sample-RAM, volatile Sample-
RAM and any connected SCSI device (optional).
SAMPLE-RAM... (F8)
This option allows you to select the Sample-RAM
that is going to store your Samples. If your in-
strument has been installed with an optional Sam-
ple-RAM kit, you will be able to choose accord-
ing to your needs.
Selecting the option opens the window where you
can choose between both types.
SCSI UTILITY
(Available only if the SCSI port has been ena-
bled by installing the optional SCSI kit).
This page offers a configuration of formatting
options for periferal SCSI devices, depending on
the current operating system running on your PS/
GPS. The following example shows one of the
possible configutations.
FAST ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a high speed method without check-
ing the medium for possible bad blocks.
ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a slower but optimsed method, check-
ing the medium for possible bad blocks. Any bad
blocks found will be masked with the resulting
reduction of the overall capacity of the disk.
ADDITIONAL DISK FUNCTIONS
This section explains the various options found
in the main Disk pages and in the File Selector,
some of which are permanent, others specific to
a particular command or disk page.
NEW FL. DISK (F5)
Updates the current directory after changing a
disk inserted in the drive, allowing the instrument
to recognize the disk change. Pressing the F5
Soft button opens the following dialog window:
You can also see the new directory by escaping
Disk mode the re-entring.
FREE MEMORY (F6)
This option displays the amount of memory re-
maining in the floppy disk, Hard disk, System-
RAM, Backed Sample-RAM, volatile Sample-
RAM and any connected SCSI device (optional).
SAMPLE-RAM... (F8)
This option allows you to select the Sample-RAM
that is going to store your Samples. If your in-
strument has been installed with an optional Sam-
ple-RAM kit, you will be able to choose accord-
ing to your needs.
Selecting the option opens the window where you
can choose between both types.
○○○○○○○○○○○○○○○○○○○○○○
Disk 4•27
○○○○○○○○○○○○○○○○○○○○○○
Disk 4•27
SCSI UTILITY
(Available only if the SCSI port has been ena-
bled by installing the optional SCSI kit).
This page offers a configuration of formatting
options for periferal SCSI devices, depending on
the current operating system running on your PS/
GPS. The following example shows one of the
possible configutations.
FAST ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a high speed method without check-
ing the medium for possible bad blocks.
ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a slower but optimsed method, check-
ing the medium for possible bad blocks. Any bad
blocks found will be masked with the resulting
reduction of the overall capacity of the disk.
ADDITIONAL DISK FUNCTIONS
This section explains the various options found
in the main Disk pages and in the File Selector,
some of which are permanent, others specific to
a particular command or disk page.
NEW FL. DISK (F5)
Updates the current directory after changing a
disk inserted in the drive, allowing the instrument
to recognize the disk change. Pressing the F5
Soft button opens the following dialog window:
You can also see the new directory by escaping
Disk mode the re-entring.
FREE MEMORY (F6)
This option displays the amount of memory re-
maining in the floppy disk, Hard disk, System-
RAM, Backed Sample-RAM, volatile Sample-
RAM and any connected SCSI device (optional).
SAMPLE-RAM... (F8)
This option allows you to select the Sample-RAM
that is going to store your Samples. If your in-
strument has been installed with an optional Sam-
ple-RAM kit, you will be able to choose accord-
ing to your needs.
Selecting the option opens the window where you
can choose between both types.
SCSI UTILITY
(Available only if the SCSI port has been ena-
bled by installing the optional SCSI kit).
This page offers a configuration of formatting
options for periferal SCSI devices, depending on
the current operating system running on your PS/
GPS. The following example shows one of the
possible configutations.
FAST ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a high speed method without check-
ing the medium for possible bad blocks.
ZIP 100 FORMAT
This operation formats a 100 Megabyte Zip™
disk using a slower but optimsed method, check-
ing the medium for possible bad blocks. Any bad
blocks found will be masked with the resulting
reduction of the overall capacity of the disk.
ADDITIONAL DISK FUNCTIONS
This section explains the various options found
in the main Disk pages and in the File Selector,
some of which are permanent, others specific to
a particular command or disk page.
NEW FL. DISK (F5)
Updates the current directory after changing a
disk inserted in the drive, allowing the instrument
to recognize the disk change. Pressing the F5
Soft button opens the following dialog window:
You can also see the new directory by escaping
Disk mode the re-entring.
FREE MEMORY (F6)
This option displays the amount of memory re-
maining in the floppy disk, Hard disk, System-
RAM, Backed Sample-RAM, volatile Sample-
RAM and any connected SCSI device (optional).
SAMPLE-RAM... (F8)
This option allows you to select the Sample-RAM
that is going to store your Samples. If your in-
strument has been installed with an optional Sam-
ple-RAM kit, you will be able to choose accord-
ing to your needs.
Selecting the option opens the window where you
can choose between both types.
