GEM GPS3600 User Manual

○○○○○○○○○○○○○○○○○○○○○○
Presets - Edit Preset 3•5
○○ ○○○○○○○○○○○○○○○○○○○○
Presets - Edit Preset 3•5
MIDI
Under MIDI, you’ll find all the elements you need
to program your Presets for any kind of MIDI
setup.
THE MIDI MENU
MIDI CHANNELS (F1)
This option allows you to set the MIDI channel
configuration for each of the 16 available tracks
and assigns the MIDI IN port, (A or B), and MIDI
OUT port, (A or B), for each track. Each track
can have separate assignments for MIDI IN and
MIDI OUT. Each Preset can have its own MIDI
channel configuration.
The parameter is divided into four parts and the
selected one is shown highlighted. Rotate the
dial to change the setting and move to the next
part with the right cursor arrow and so on..
The first part represents the MIDI IN port, the sec-
ond represents the MIDI IN channel, the third the
MIDI OUT port and the fourth the MIDI OUT chan-
nel.
MIDI IN port
(A or B)
MIDI OUT
channel
(1...16)
MIDI OUT
port (A or B)
MIDI IN
channel
(1...16)
CONFIGURATION (F2)
Use this option to set the track configuration of
each of the 16 available tracks of your Preset.
You can choose which tracks respond to MIDI In
messages, which ones react with the instrument’s
internal generator, which direct their messages
to MIDI OUT and which ones do not respond to
any information.
Just like the MIDI channel parameter, the Con-
figuration parameter is divided into four parts and
the selected one is shown highlighted. Rotate
the dial to change the setting and move to the
next part with the right cursor arrow and so on..
keyboard/
Common Channel
MIDI
IN
internal sound
generator
MIDI
OUT
When an icon is shown, the parameter is on;
when OFF appears in place of the icon, the pa-
rameter is deactivated.
MIDI IN ICON: When on (icon showing), the track
responds to MIDI data received at the MIDI IN
port. When OFF, the track does not receive ex-
ternal MIDI data.
KEYBOARD/COMMON CHANNEL ICON: The
track responds to the PS/GPS keyboard, or to
an external controlling device (master keyboard)
transmitting to the PS/GPS via the Common
Channel. The common channel allows a remote
controller keyboard to emulate the internal key-
board of the PS/GPS.
