GEM GPS3600 User Manual

○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•33
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•33
(GENERAL) NOTE TUNING/SCALE ( xx = NOTE = 0 - 7F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 06 00 00 00 01 00 7F coarse 0 -> 127
xx 06 01 00 00 01 01 7F finetune -63 -> +63;
(GENERAL) TUNING/SCALE
Address(H) Size (H) Range(H) Parameter Description Default
00 07 00 00 00 01 01 7F Master_pitch -63 -> +63; 0
00 07 01 00 00 01 00 0D kbd_scale 0 -> +13 0=Equal
MIDI CLOCK
Address(H) Size (H) Range(H) Parameter Description Default
00 08 00 00 00 01 00 01 MidiClock Int/Ext 0=Internal
GLOBAL SET
Address(H) Size (H) Range(H) Parameter Description Default
00 09 02 00 00 01 00 30 transpose -24 +24 [semitones] 18H = 0
MIDI GENERAL SET
Address(H) Size (H) Range(H) Parameter Description Default
00 0A 00 00 00 01 00 10 Common_ch 0=Off; 1->10 = chan 1->16 0 = Off
00 0A 01 00 00 01 01 02 Common_In 1 = MidiIn A, 2= MidiIn B 1 = In A
00 0A 02 00 00 01 01 02 Common_Out 1 = MidiOut A, 2= MidiOut B 1 = Out A
00 0A 03 00 00 01 00 01 Midi_lock 1 = On
00 0A 04 00 00 01 00 01 Clock_Send 1 = On
00 0A 05 00 00 01 00 01 Midi_Merge 0 = Off
00 0A 06 00 00 01 00 01 MidiInTran 0 = Off
00 0A 07 00 00 01 00 7F MidiFixedDyn 0 -> 127 0 = Off
00 0A 08 00 00 01 00 01 Midi_sysex 0=Excl System OFF, 1=ON 1 = On
00 0A 09 00 00 01 00 01 SMF saveFrm 0 = GMidi, 1 = smfformat 0=GMidi
00 0A 0A 00 00 01 00 01 Bank_select 1
(GENERAL) MIC/LINE INPUT 1
Address(H) Size (H) Range(H) Parameter Description Default
00 0B 00 00 00 01 00 7F Volume 0 -> 127 7FH =127
00 0B 01 00 00 01 00 01 EffGroup 0
00 0B 02 00 00 01 00 7F Eff1Send 0 -> 127 40H = 64
00 0B 03 00 00 01 00 7F Eff2Send 0 -> 127 40H = 64
00 0B 04 00 00 01 00 05 FltType 0
00 0B 05 00 00 01 00 BF FltCutoff 0 191, Use nibblized if > 127 0
00 0B 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0B 07 00 00 01 00 3E Pan -31 -> +31 3EH = 31
00 0B 08 00 00 01 00 03 AnalogOut 0
00 0B 09 00 00 01 00 01 Mic/Line On/Off 0
(GENERAL) MIC/LINE INPUT 2
Address(H) Size (H) Range(H) Parameter Description Default
00 0C 00 00 00 01 00 7F Volume 0 -> 127 7FH=127
00 0C 01 00 00 01 00 01 EffGroup 0
00 0C 02 00 00 01 00 7F Eff1Send 0 -> 127 40H= 64
00 0C 03 00 00 01 00 7F Eff2Send 0 -> 127 40H= 64
00 0C 04 00 00 01 00 05 FltType 0
00 0C 05 00 00 01 00 BF FltCutoff 0->191, Use nibblized if >127 0
00 0C 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0C 07 00 00 01 00 3E Pan -31 -> +31 3EH= 31
00 0C 08 00 00 01 00 03 AnalogOut 0
00 0C 09 00 00 01 00 01 Mic/Line On/Off 0
(GENERAL) NOTE TUNING/SCALE ( xx = NOTE = 0 - 7F )
Address(H)
Size (H) Range(H)
Parameter
Description
Default
xx 06 00 00 00 01 00 7F coarse 0 -> 127
xx 06 01 00 00 01 01 7F finetune -63 -> +63;
(GENERAL) TUNING/SCALE
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 07 00 00 00 01 01 7F Master_pitch -63 -> +63; 0
00 07 01 00 00 01 00 0D kbd_scale 0 -> +13 0=Equal
MIDI CLOCK
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 08 00 00 00 01 00 01 MidiClock Int/Ext 0=Internal
GLOBAL SET
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 09 02 00 00 01 00 30 transpose -24 +24 [semitones] 18H = 0
MIDI GENERAL SET
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 0A 00 00 00 01 00 10 Common_ch 0=Off; 1->10 = chan 1->16 0 = Off
00 0A 01 00 00 01 01 02 Common_In 1 = MidiIn A, 2= MidiIn B 1 = In A
00 0A 02 00 00 01 01 02 Common_Out 1 = MidiOut A, 2= MidiOut B 1 = Out A
00 0A 03 00 00 01 00 01 Midi_lock 1 = On
00 0A 04 00 00 01 00 01 Clock_Send 1 = On
00 0A 05 00 00 01 00 01 Midi_Merge 0 = Off
00 0A 06 00 00 01 00 01 MidiInTran 0 = Off
00 0A 07 00 00 01 00 7F MidiFixedDyn 0 -> 127 0 = Off
00 0A 08 00 00 01 00 01 Midi_sysex 0=Excl System OFF, 1=ON 1 = On
00 0A 09 00 00 01 00 01 SMF saveFrm 0 = GMidi, 1 = smfformat 0=GMidi
00 0A 0A 00 00 01 00 01 Bank_select 1
(GENERAL) MIC/LINE INPUT 1
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 0B 00 00 00 01 00 7F Volume 0 -> 127 7FH =127
00 0B 01 00 00 01 00 01 EffGroup 0
00 0B 02 00 00 01 00 7F Eff1Send 0 -> 127 40H = 64
00 0B 03 00 00 01 00 7F Eff2Send 0 -> 127 40H = 64
00 0B 04 00 00 01 00 05 FltType 0
00 0B 05 00 00 01 00 BF FltCutoff 0 191, Use nibblized if > 127 0
00 0B 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0B 07 00 00 01 00 3E Pan -31 -> +31 3EH = 31
00 0B 08 00 00 01 00 03 AnalogOut 0
00 0B 09 00 00 01 00 01 Mic/Line On/Off 0
(GENERAL) MIC/LINE INPUT 2
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 0C 00 00 00 01 00 7F Volume 0 -> 127 7FH=127
00 0C 01 00 00 01 00 01 EffGroup 0
00 0C 02 00 00 01 00 7F Eff1Send 0 -> 127 40H= 64
00 0C 03 00 00 01 00 7F Eff2Send 0 -> 127 40H= 64
00 0C 04 00 00 01 00 05 FltType 0
00 0C 05 00 00 01 00 BF FltCutoff 0->191, Use nibblized if >127 0
00 0C 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0C 07 00 00 01 00 3E Pan -31 -> +31 3EH= 31
00 0C 08 00 00 01 00 03 AnalogOut 0
00 0C 09 00 00 01 00 01 Mic/Line On/Off 0
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•33
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•33
(GENERAL) NOTE TUNING/SCALE ( xx = NOTE = 0 - 7F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 06 00 00 00 01 00 7F coarse 0 -> 127
xx 06 01 00 00 01 01 7F finetune -63 -> +63;
(GENERAL) TUNING/SCALE
Address(H) Size (H) Range(H) Parameter Description Default
00 07 00 00 00 01 01 7F Master_pitch -63 -> +63; 0
00 07 01 00 00 01 00 0D kbd_scale 0 -> +13 0=Equal
MIDI CLOCK
Address(H) Size (H) Range(H) Parameter Description Default
00 08 00 00 00 01 00 01 MidiClock Int/Ext 0=Internal
GLOBAL SET
Address(H) Size (H) Range(H) Parameter Description Default
00 09 02 00 00 01 00 30 transpose -24 +24 [semitones] 18H = 0
MIDI GENERAL SET
Address(H) Size (H) Range(H) Parameter Description Default
00 0A 00 00 00 01 00 10 Common_ch 0=Off; 1->10 = chan 1->16 0 = Off
00 0A 01 00 00 01 01 02 Common_In 1 = MidiIn A, 2= MidiIn B 1 = In A
00 0A 02 00 00 01 01 02 Common_Out 1 = MidiOut A, 2= MidiOut B 1 = Out A
00 0A 03 00 00 01 00 01 Midi_lock 1 = On
00 0A 04 00 00 01 00 01 Clock_Send 1 = On
00 0A 05 00 00 01 00 01 Midi_Merge 0 = Off
00 0A 06 00 00 01 00 01 MidiInTran 0 = Off
00 0A 07 00 00 01 00 7F MidiFixedDyn 0 -> 127 0 = Off
00 0A 08 00 00 01 00 01 Midi_sysex 0=Excl System OFF, 1=ON 1 = On
00 0A 09 00 00 01 00 01 SMF saveFrm 0 = GMidi, 1 = smfformat 0=GMidi
00 0A 0A 00 00 01 00 01 Bank_select 1
(GENERAL) MIC/LINE INPUT 1
Address(H) Size (H) Range(H) Parameter Description Default
00 0B 00 00 00 01 00 7F Volume 0 -> 127 7FH =127
00 0B 01 00 00 01 00 01 EffGroup 0
00 0B 02 00 00 01 00 7F Eff1Send 0 -> 127 40H = 64
00 0B 03 00 00 01 00 7F Eff2Send 0 -> 127 40H = 64
00 0B 04 00 00 01 00 05 FltType 0
00 0B 05 00 00 01 00 BF FltCutoff 0 191, Use nibblized if > 127 0
00 0B 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0B 07 00 00 01 00 3E Pan -31 -> +31 3EH = 31
00 0B 08 00 00 01 00 03 AnalogOut 0
00 0B 09 00 00 01 00 01 Mic/Line On/Off 0
(GENERAL) MIC/LINE INPUT 2
Address(H) Size (H) Range(H) Parameter Description Default
00 0C 00 00 00 01 00 7F Volume 0 -> 127 7FH=127
00 0C 01 00 00 01 00 01 EffGroup 0
00 0C 02 00 00 01 00 7F Eff1Send 0 -> 127 40H= 64
00 0C 03 00 00 01 00 7F Eff2Send 0 -> 127 40H= 64
00 0C 04 00 00 01 00 05 FltType 0
00 0C 05 00 00 01 00 BF FltCutoff 0->191, Use nibblized if >127 0
00 0C 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0C 07 00 00 01 00 3E Pan -31 -> +31 3EH= 31
00 0C 08 00 00 01 00 03 AnalogOut 0
00 0C 09 00 00 01 00 01 Mic/Line On/Off 0
(GENERAL) NOTE TUNING/SCALE ( xx = NOTE = 0 - 7F )
Address(H)
Size (H) Range(H)
Parameter
Description
Default
xx 06 00 00 00 01 00 7F coarse 0 -> 127
xx 06 01 00 00 01 01 7F finetune -63 -> +63;
(GENERAL) TUNING/SCALE
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 07 00 00 00 01 01 7F Master_pitch -63 -> +63; 0
00 07 01 00 00 01 00 0D kbd_scale 0 -> +13 0=Equal
MIDI CLOCK
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 08 00 00 00 01 00 01 MidiClock Int/Ext 0=Internal
GLOBAL SET
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 09 02 00 00 01 00 30 transpose -24 +24 [semitones] 18H = 0
MIDI GENERAL SET
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 0A 00 00 00 01 00 10 Common_ch 0=Off; 1->10 = chan 1->16 0 = Off
00 0A 01 00 00 01 01 02 Common_In 1 = MidiIn A, 2= MidiIn B 1 = In A
00 0A 02 00 00 01 01 02 Common_Out 1 = MidiOut A, 2= MidiOut B 1 = Out A
00 0A 03 00 00 01 00 01 Midi_lock 1 = On
00 0A 04 00 00 01 00 01 Clock_Send 1 = On
00 0A 05 00 00 01 00 01 Midi_Merge 0 = Off
00 0A 06 00 00 01 00 01 MidiInTran 0 = Off
00 0A 07 00 00 01 00 7F MidiFixedDyn 0 -> 127 0 = Off
00 0A 08 00 00 01 00 01 Midi_sysex 0=Excl System OFF, 1=ON 1 = On
00 0A 09 00 00 01 00 01 SMF saveFrm 0 = GMidi, 1 = smfformat 0=GMidi
00 0A 0A 00 00 01 00 01 Bank_select 1
(GENERAL) MIC/LINE INPUT 1
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 0B 00 00 00 01 00 7F Volume 0 -> 127 7FH =127
00 0B 01 00 00 01 00 01 EffGroup 0
00 0B 02 00 00 01 00 7F Eff1Send 0 -> 127 40H = 64
00 0B 03 00 00 01 00 7F Eff2Send 0 -> 127 40H = 64
00 0B 04 00 00 01 00 05 FltType 0
00 0B 05 00 00 01 00 BF FltCutoff 0 191, Use nibblized if > 127 0
00 0B 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0B 07 00 00 01 00 3E Pan -31 -> +31 3EH = 31
00 0B 08 00 00 01 00 03 AnalogOut 0
00 0B 09 00 00 01 00 01 Mic/Line On/Off 0
(GENERAL) MIC/LINE INPUT 2
Address(H)
Size (H) Range(H)
Parameter
Description
Default
00 0C 00 00 00 01 00 7F Volume 0 -> 127 7FH=127
00 0C 01 00 00 01 00 01 EffGroup 0
00 0C 02 00 00 01 00 7F Eff1Send 0 -> 127 40H= 64
00 0C 03 00 00 01 00 7F Eff2Send 0 -> 127 40H= 64
00 0C 04 00 00 01 00 05 FltType 0
00 0C 05 00 00 01 00 BF FltCutoff 0->191, Use nibblized if >127 0
00 0C 06 00 00 01 00 7f FltResonance 0 -> 127 0
00 0C 07 00 00 01 00 3E Pan -31 -> +31 3EH= 31
00 0C 08 00 00 01 00 03 AnalogOut 0
00 0C 09 00 00 01 00 01 Mic/Line On/Off 0
