GEM GPS3600 User Manual

○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•37
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•37
DYNAMIC SWITCH
Address(H) Size (H) Range(H) Parameter Description Default
00 1E 00 00 00 01 00 7F DynSwitch 00 127
LAYER2 SOUND PATCH ( xx = NOTE = 0 - 7F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 1F 00 00 00 02 0: 7F+0:F Soundnr Prog.Change + Bank
xx 1F 01 00 00 01 00 7F Level 00 127
xx 1F 02 00 00 01 00 7F Panorama -64 +63
xx 1F 03 00 00 01 00 7F Transpose -64 +63
xx 1F 04 00 00 01 00 7F Tune -64 +63
xx 1F 05 00 00 01 00 7F FltCutOff -64 +63
xx 1F 06 00 00 01 00 03 Exclude 00 03
xx 1F 07 00 00 01 00 7F Effect 1 00 127
xx 1F 08 00 00 01 00 7F Effect 2 00 127
xx 1F 09 00 00 01 00 04 Analog Out 00=track,1=L+R,2=O1+O2,3=O1,4=O2
TRACK SELECT
Address(H) Size (H) Range(H) Parameter Description Default
00 20 00 00 00 01 00 1F Selected 00 31
SYSTEM OBJECT ACCESS MESSAGES
SYSTEM RESOURCE ACCESS
Messages relating to the RESOURCE ACCESS allow the transfer via MIDI of the same basic resources of the instrument that can
be exported to disk, and which are:
∑ System SETUP
∑ SOUNDS
∑ GLOBAL PRESETS
∑ STYLE PRESETS
∑ USER STYLES
∑ SONGS
Each type of resource can constitute several files, in which case, before transmitting, are compacted into a single data block..
The transmission can take place in handshake mode for higher speeds and better control of the data transmitted (the system
automatically recognizes the mode utilized according to the reply given or not after the transmission of the File Header Message).
The MIDI message transmitted consists of the following structure:
F0H = System Exclusive Message status
2FH = ID number (manufacturer ID) = GENERAL MUSIC
5cH = Command ID: 5=Resource Access, c=device ID(0-F)
6
ss = Subfunction ID
id = Model ID, 00 = WK4
cf = c = checksum (0-1), f = Data Format (0-3)
pp = packet number (optional)
<data> = (optional)
cc = checksum (optional)
F7H = EOX
Subfunction ID: File Header 01H
File Data 02H
Resource Request 03H
Parametr Request 40H
Parameter Data 41H
7
ACK 7FH
DYNAMIC SWITCH
Address(H)
Size (H)
Range(H)
Parameter Description
Default
00 1E 00 00 00 01 00 7F DynSwitch 00 127
LAYER2 SOUND PATCH ( xx = NOTE = 0 - 7F )
Address(H)
Size (H)
Range(H)
Parameter Description
Default
xx 1F 00 00 00 02 0: 7F+0:F Soundnr Prog.Change + Bank
xx 1F 01 00 00 01 00 7F Level 00 127
xx 1F 02 00 00 01 00 7F Panorama -64 +63
xx 1F 03 00 00 01 00 7F Transpose -64 +63
xx 1F 04 00 00 01 00 7F Tune -64 +63
xx 1F 05 00 00 01 00 7F FltCutOff -64 +63
xx 1F 06 00 00 01 00 03 Exclude 00 03
xx 1F 07 00 00 01 00 7F Effect 1 00 127
xx 1F 08 00 00 01 00 7F Effect 2 00 127
xx 1F 09 00 00 01 00 04 Analog Out 00=track,1=L+R,2=O1+O2,3=O1,4=O2
TRACK SELECT
Address(H)
Size (H)
Range(H)
Parameter Description
Default
00 20 00 00 00 01 00 1F Selected 00 31
SYSTEM OBJECT ACCESS MESSAGES
SYSTEM RESOURCE ACCESS
Messages relating to the RESOURCE ACCESS allow the transfer via MIDI of the same basic resources of the instrument that can
be exported to disk, and which are:
∑
System SETUP
∑
SOUNDS
∑
GLOBAL PRESETS
∑
STYLE PRESETS
∑
USER STYLES
∑
SONGS
Each type of resource can constitute several files, in which case, before transmitting, are compacted into a single data block..
The transmission can take place in handshake mode for higher speeds and better control of the data transmitted (the system
automatically recognizes the mode utilized according to the reply given or not after the transmission of the File Header Message).
The MIDI message transmitted consists of the following structure:
F0H = System Exclusive Message status
2FH = ID number (manufacturer ID) = GENERAL MUSIC
5cH = Command ID: 5=Resource Access, c=device ID(0-F)
6
ss = Subfunction ID
id = Model ID, 00 = WK4
cf = c = checksum (0-1), f = Data Format (0-3)
pp = packet number (optional)
<data> = (optional)
cc = checksum (optional)
F7H = EOX
Subfunction ID: File Header 01H
File Data 02H
Resource Request 03H
Parametr Request 40H
Parameter Data 41H
7
ACK 7FH
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•37
○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•37
DYNAMIC SWITCH
Address(H) Size (H) Range(H) Parameter Description Default
00 1E 00 00 00 01 00 7F DynSwitch 00 127
LAYER2 SOUND PATCH ( xx = NOTE = 0 - 7F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 1F 00 00 00 02 0: 7F+0:F Soundnr Prog.Change + Bank
xx 1F 01 00 00 01 00 7F Level 00 127
xx 1F 02 00 00 01 00 7F Panorama -64 +63
xx 1F 03 00 00 01 00 7F Transpose -64 +63
xx 1F 04 00 00 01 00 7F Tune -64 +63
xx 1F 05 00 00 01 00 7F FltCutOff -64 +63
xx 1F 06 00 00 01 00 03 Exclude 00 03
xx 1F 07 00 00 01 00 7F Effect 1 00 127
xx 1F 08 00 00 01 00 7F Effect 2 00 127
xx 1F 09 00 00 01 00 04 Analog Out 00=track,1=L+R,2=O1+O2,3=O1,4=O2
TRACK SELECT
Address(H) Size (H) Range(H) Parameter Description Default
00 20 00 00 00 01 00 1F Selected 00 31
SYSTEM OBJECT ACCESS MESSAGES
SYSTEM RESOURCE ACCESS
Messages relating to the RESOURCE ACCESS allow the transfer via MIDI of the same basic resources of the instrument that can
be exported to disk, and which are:
∑ System SETUP
∑ SOUNDS
∑ GLOBAL PRESETS
∑ STYLE PRESETS
∑ USER STYLES
∑ SONGS
Each type of resource can constitute several files, in which case, before transmitting, are compacted into a single data block..
The transmission can take place in handshake mode for higher speeds and better control of the data transmitted (the system
automatically recognizes the mode utilized according to the reply given or not after the transmission of the File Header Message).
The MIDI message transmitted consists of the following structure:
F0H = System Exclusive Message status
2FH = ID number (manufacturer ID) = GENERAL MUSIC
5cH = Command ID: 5=Resource Access, c=device ID(0-F)
6
ss = Subfunction ID
id = Model ID, 00 = WK4
cf = c = checksum (0-1), f = Data Format (0-3)
pp = packet number (optional)
<data> = (optional)
cc = checksum (optional)
F7H = EOX
Subfunction ID: File Header 01H
File Data 02H
Resource Request 03H
Parametr Request 40H
Parameter Data 41H
7
ACK 7FH
DYNAMIC SWITCH
Address(H)
Size (H)
Range(H)
Parameter Description
Default
00 1E 00 00 00 01 00 7F DynSwitch 00 127
LAYER2 SOUND PATCH ( xx = NOTE = 0 - 7F )
Address(H)
Size (H)
Range(H)
Parameter Description
Default
xx 1F 00 00 00 02 0: 7F+0:F Soundnr Prog.Change + Bank
xx 1F 01 00 00 01 00 7F Level 00 127
xx 1F 02 00 00 01 00 7F Panorama -64 +63
xx 1F 03 00 00 01 00 7F Transpose -64 +63
xx 1F 04 00 00 01 00 7F Tune -64 +63
xx 1F 05 00 00 01 00 7F FltCutOff -64 +63
xx 1F 06 00 00 01 00 03 Exclude 00 03
xx 1F 07 00 00 01 00 7F Effect 1 00 127
xx 1F 08 00 00 01 00 7F Effect 2 00 127
xx 1F 09 00 00 01 00 04 Analog Out 00=track,1=L+R,2=O1+O2,3=O1,4=O2
TRACK SELECT
Address(H)
Size (H)
Range(H)
Parameter Description
Default
00 20 00 00 00 01 00 1F Selected 00 31
SYSTEM OBJECT ACCESS MESSAGES
SYSTEM RESOURCE ACCESS
Messages relating to the RESOURCE ACCESS allow the transfer via MIDI of the same basic resources of the instrument that can
be exported to disk, and which are:
∑
System SETUP
∑
SOUNDS
∑
GLOBAL PRESETS
∑
STYLE PRESETS
∑
USER STYLES
∑
SONGS
Each type of resource can constitute several files, in which case, before transmitting, are compacted into a single data block..
The transmission can take place in handshake mode for higher speeds and better control of the data transmitted (the system
automatically recognizes the mode utilized according to the reply given or not after the transmission of the File Header Message).
The MIDI message transmitted consists of the following structure:
F0H = System Exclusive Message status
2FH = ID number (manufacturer ID) = GENERAL MUSIC
5cH = Command ID: 5=Resource Access, c=device ID(0-F)
6
ss = Subfunction ID
id = Model ID, 00 = WK4
cf = c = checksum (0-1), f = Data Format (0-3)
pp = packet number (optional)
<data> = (optional)
cc = checksum (optional)
F7H = EOX
Subfunction ID: File Header 01H
File Data 02H
Resource Request 03H
Parametr Request 40H
Parameter Data 41H
7
ACK 7FH
