11
Router Stand Assembly
Warning: THIS PROCEDURE REQUIRES AT LEAST FOUR
PERSONS TO LIFT THE ROUTER TABLE BECAUSE OF ITS
WEIGHT.
CAUTION: When removing the four foot subassemblies from
the Dimension 200 router table, do not set the table on the
ground. Damage to the undercarriage will occur. Use the
wooden packing materials to block up the router table.
Assemble the Leg Assembly
1.
Unpack the router and use the wooden packing materials to
block up the router table.
2.
Unscrew and remove the four foot subassemblies from the
bottom of the Dimension 200 router table.
3.
Attach one foot subassembly to the bottom of each leg of the
stand (as shown on the next page) using the specified parts.
DO NOT tighten the nuts or install the M8 bolt and washer at
the top of each leg at this time.
Note: The top of each leg has one bolt hole on each outside surface. The
bottom of each leg has three bolt holes on each outside surface. Refer to
the Assembled Stand figure.
