54
Dimension 200
ABSOLUTE X,Y:
The Absolute X,Y function displays the exact position of the
router tool relative to the absolute 0,0 position on the router table
established during orientation when the router was turned on.
The Absolute X,Y display allows the operator to position the
router tool with great precision and helps set the job home
position. Each coordinate is precise to three decimal places
(000.000) in inches, two decimal places (0000.00) in mm.
To display the absolute X,Y position
1.
Press SELECT while in the STOP READY or STOP JOB mode.
2.
Press the right or left arrow key until Absolute (X,Y): appears
in the message box.
3.
Press SELECT to display the current position.
X: +000.000 INCH
Y: +000.000 INCH
4.
Press any arrow key to move the router carriage. The message
box will display the new coordinate position when the arrow
key(s) are released.
5.
Press any key to exit.
