System Preparation and Use 67
Router Motor Installation/Removal
For your convenience, the Dimension 200 is shipped with the
router motor already installed. However, should a problem occur
requiring the motor to be removed, please follow the instructions
below.
To remove the router motor
1.
Turn off and unplug power at the router, electrical box, and
GRAPHIX ADVANTAGE.
2.
Loosen the screws on the collar of the motor mount and
carefully slide the motor up the mount to remove it.
To install the router motor
Note: The photograph below is for illustration purposes only and may
vary somewhat from your router motor.
1.
Locate the router motor and note the small pin or pins
(depending on the model) projecting from it.
2.
Ease the router motor into the motor mount, matching the
pins to the grooves.
3.
Slide the motor to the bottom of the mount.
