JOB HOME POSITION AND JOB BOUNDARIES
Job boundaries cannot exceed the active cutting area of the router
table. The Dimension 200 and ART Path interpret job boundaries
for certain job types in these ways:

Output repeats are considered to include all repeats within
the job boundary.

Paneled jobs are treated as separate jobs. The largest panel
must fit on the table.

Inplace repeats include the park position within the job
boundary.

PrePosition set in ART Path is included in the job boundary.
If the Job Home position will cause the job being processed to
exceed the table boundaries, the ARC station displays
JOB WILL
EXCEED TABLE BOUNDARY
in the message box.
To clear the boundary message
1. Press START/STOP to display the correction necessary to
permit the job to fit.
2. Press the arrow keys to move the carriage the distance in X
and Y indicated in the message. When the carriage is in an
acceptable position, the X and Y distances will be zero.
3. Press START/STOP again. If the job still exceeds boundaries,
the correction message is displayed again. If the job fits,
PRESS START TO SET HOME
is displayed.
4. Press START/STOP again to set the current position as Job
Home and start the job.
