Operating Principles 57
To display current job home
1.
To avoid hitting clamps, slew the carriage near the home
position using the arrow keys.
2.
Press SELECT while in the STOP READY or STOP JOB mode.
3.
Press the right or left arrow key until
RETURN HOME
appears
in the message box.
4.
Press SELECT to move the carriage to the precise Job Home
position.
5.
Press the right or left arrow key until Absolute (X,Y): appears
in the message box.
6.
Press SELECT to display the current position. This is the
current Job Home position.
Note: Make note of this position. If the carriage hits a clamp or
fixture and router position is lost, you can slew to this position or
set an absolute pre-position in ART Path and repeat the job, but
only if you reorient the system by turning the power off and then on
again.
