The function keys located on the front panel of the ARC station
perform specific routines. Each function key is discussed
individually in the following pages.
ARROW KEYS
The arrow keys are most frequently used to slew the router
carriage into position. Slewing refers to positioning the X and Y
axes where desired.
The arrow keys are also used to scroll through available choices at
the ARC station after a selection has been made in the Menu
Select mode. See the page in this section on Menu Select mode.
To slew the Dimension 200

To position the tool to the left or right over the router table
surface, press the left or right arrow keys until the desired
placement is reached.

To position the tool forward or backward over the table
surface, press the up or down arrow keys until the desired
placement is reached.

To slew diagonally, press two keys at the same time (left or
right with up or down).

You cannot slew past the table edges if the limit switches have
been set.
