Operating Principles 53
Using Select
To access the Menu Select mode, press SELECT while in the STOP
READY or STOP JOB mode.
The choices available are as follows:
Absolute (X,Y):
Set Job Home
Return Home
Feed Rate:
Motor Delay:
Test:
Display:
Default
Note: A colon (:) following a menu selection indicates additional choices
are available when the item is selected. Each menu selection is explained
and contains directions on changing parameters.
To exit the Menu Select mode and return to STOP mode without
changing settings, press RESET.
To make a selection in Menu Select mode
1.
Press the right arrow key to scroll forward (right) through the
menu list or press the left arrow key to scroll backward (left)
through the menu list.
2.
When the desired menu item appears, press the SELECT key
to display the choices available under the selected menu item
if the item is followed by a colon (:), or to execute the function.
3.
Use the arrow keys to display available choices.
