15
Router Installation Procedure
Before You Begin
WARNING: Turn OFF power to the GRAPHIX ADVANTAGE
and unplug the system from the outlet. DO NOT plug in power
until instructed to do so.
WARNING: Turn OFF and unplug any lettering systems or
plotters connected to the GRAPHIX ADVANTAGE.
WARNING: THE MAIN POWER BREAKER SWITCH ON
THE FRONT PANEL OF THE ELECTRICAL BOX MUST BE
OFF (POINTING DOWN). THE ROUTER MOTOR SWITCH
(LOCATED ON THE ROUTER MOTOR) MUST BE OFF.
Note: Should problems occur while you install the hardware to your
system, contact the Router Support Group at 800-336-1698 (USA and
Canada) or fax at 203-290-5568.
Power Off Check
The main power breaker switch on the front panel of the
electrical box must be OFF (pointing down).
