Operating Principles 59
RETURN HOME
The Return Home feature allows the operator to return the
carriage to the last Job Home position. The Job Home position is
stored when a job is started or when the Set Job Home function is
used.
To return home
1.
To avoid hitting clamps or fixtures, move the carriage near the
home position using the arrow keys.
2.
Press SELECT while in the STOP READY or STOP JOB mode.
3.
Press the right or left arrow key until
RETURN HOME
appears
in the message box.
4.
Press SELECT to move the carriage to the precise Job Home
position.
FEED RATE:
The Feed Rate is set in ART Path at the GRAPHIX ADVANTAGE.
It is the absolute speed in inches per minute or millimeters per
second at which the tool travels along the tool path. To override
this rate and reduce or increase the feed rate, change the
established Feed Rate by a percentage described below. The feed
rate will not exceed maximum velocity of the router.
The Feed Rate parameter is most frequently changed in the STOP
JOB mode when the Feed Rate has been set too high or too low for
the job in progress. The feed rate override is not cleared after the
job completes and will be applied to the next job.
The feed rate will not exceed maximum velocity of the router.
How-ever, if the Feed Rate set in ART Path is less than the
maximum, you may increase it using the Feed Rate parameter. A
Feed Rate of 200% would double the Feed Rate set in ART Path.
