System Preparation and Use 71
TOOL INSTALLATION
Solid carbide tools, such as those included in the tool kit, must be
handled very carefully.
caution: DO NOT STRIKE THE CUTTING EDGE WITH THE
COLLET OR ADAPTER DURING TOOL INSTALLATION.
To install the tool
1.
Turn OFF the router motor.
2.
Select the desired tool and the appropriate collet from the tool
kit.
3.
Insert the tool into the collet and tighten with the wrenches
provided in the tool kit.
When installing the pen, position the bottom of the collet
about half-way up the shank of the tool.
When installing a cutter, position the bottom of the collet
approximately even with the top of the flutes. The collet
should not cover any portion of the flutes, and very little of
the straight portion of the shank should be exposed below the
collet.
4.
Slew the carriage to near the front edge of the router table.
5.
Remove the retaining nut from the base of the router motor
using the wrenches supplied in the tool kit.
