Gerber Dimension 200 - Using the Speed Controller System

32
Dimension 200
USING THE SPEED CONTROLLER SYSTEM
The Speed Controller System is used to control the spindle speed
of the High Frequency Spindle motor. The thickness and type of
material, as well as the tool selected, determine the correct spindle
speed. The recommended speed for various materials may be
found at the end of this manual.
The speed selection knob located on the Speed Controller selects a
spindle speed as follows:
Knob Spindle Speed
00
10 2,800
20 5,600
30 9,400
40 12,200
50 14,000
60 16,800
70 19,600
80 22,400
90 25,200
100 28,000
Note: The Speed Controller System must be installed by a qualified
electrician. Installation instructions are supplied with the speed
controller.
