Optional Equipment Installation 33
Engraver Vacuum System Option
The optional Engraver Vacuum System is a quiet, conveniently-
sized system used to clean debris from the table and engraving
area.
To assemble the Engraver Vacuum System
1.
Remove and discard the plugs from the holes labeled IN and
OUT on the front of the vacuum motor.
2.
Thread the long end of the pipe elbow into the "in" receptacle
on the vacuum motor and tighten. Make sure the elbow
points up.
3.
Insert the short pipe fitting into the end of the protruding
elbow and tighten.
4.
Place the vacuum tank on the short pipe fitting and rotate the
tank to tighten.
5.
To securely tighten the entire attached assembly, one person
should hold down the motor while another person turns the
entire assembly until it is tight.
6.
Insert the reducer fitting into the hole on top of the vacuum
tank and tighten.
7.
Insert the barbed fitting into the reducer fitting and tighten.
8.
Slip one end of the hose over the end of the barbed fitting on
top of the tank.
9.
Place the assembled vacuum system near the router,
preferably on the right side.
