74
Dimension 200
To remove a tool
1.
Use the slew keys to position the carriage near the front of the
router table.
2.
Turn OFF the router motor.
3.
Loosen the retaining nut using one wrench while holding the
router motor chuck firmly with the other wrench.
4.
Remove the tool from the collet.
PEN TOOL REPLACEMENT
To replace a pen
1.
Unscrew the top of the pen assembly.
2.
Remove the spring.
3.
Remove the pen.
4.
Insert the replacement pen into the pen barrel.
5.
Replace the spring, and replace the cover on top of the barrel.
REPLACEMENT CUTTERS
Replacement cutters are available from Gerber. Different cutters
purchased from other dealers may or may not provide satisfactory
results with the Dimension 200.
Gerber is not responsible for results obtained with cutters not
recommended in this manual or purchased from other dealers. Be
sure to get only the highest quality cutters for use with the
Dimension 200.
