20
Dimension 200
3.
Now lead the vacuum hose and ground strap to the shop
vacuum canister, inserting some of the ground strap into the
canister.
4.
Make sure that some of the ground strap still extends from the
vacuum hose and that there is enough slack on the ground
strap. (The ground strap goes in and comes back out of the
canister to connect to the electrical box in the next procedure.)
Connect the Ground Strap Cables
Ground strap cables are static protection devices that reduce the
risk of static electricity damage to the router system's integrated
circuitry. The Dimension 200 comes equipped with three ground
strap cables which connect as follows:
ARC station to the electrical box
foot mount block on the Dimension 200 router table to the
electrical box
vacuum hose pressure foot to the electrical box.
All three ground strap cables must connect at the same point on
the electrical box. Both ends of all ground strap cables must be
securely fastened to ensure a reliable ground connection.
To connect the ground strap cable at the router table
1.
At the left rear of the Dimension 200 router table, remove the
left capscrew that secures the foot mount block to the router
bed.
2.
Locate the ground strap cable (recognizable by the yellow ring
lug) fastened to the limit switch and motor cables.
3.
Insert the capscrew through the ground strap ring lug and
reinstall.
4.
Securely tighten the capscrew to ensure a reliable ground
connection.
