Router Installation Procedure 19
To install the vacuum shroud
The vacuum shroud is installed by Gerber. Should you need to
reinstall it, follow the procedure below.
1.
Align the screw holes on the vacuum shroud with the screw
holes in the carriage sidewalls.
2.
Insert and tighten the screws.
To attach the vacuum hose
1.
Attach the vacuum hose onto the pressure foot of the
Dimension 200. (One end of the ground strap cable is already
connected at this end in the interior of the hose.)
2.
Lead the vacuum hose and the ground strap which extends
from the end of the vacuum hose to the electrical box. Make
sure that there is ample slack on the strap to comfortably
connect in the next procedure.
