Operating Principles 45
START/STOP
This key toggles between the START and STOP modes.
Start Mode
START mode, as shown by a message in the display panel, may
be in one of two states:
START READY - the system is ready to receive a job
START JOB - the system has received a job and is processing it
The following keys are available in START mode:
RESET - immediately aborts router movement and purges the
job
START/STOP - pauses processing the job
Start Ready
WARNING: In START READY mode, the carriage may move
without further warning.
1.
While in the STOP READY mode, use the arrow keys to slew
the carriage to the starting location of the job.
2.
Press the START/STOP key to display the
START READY
message.
The Dimension 200 is now in a “ready” state and the message
remains until the data arrives from the GRAPHIX ADVANTAGE.
The current tool position becomes the start point for the job.
