7
INSTALLATION
Unpack the plotter boxes and inventory the contents before you begin to
assemble the plotter. Follow these instructions to install the HS15
plus
plotter to the
GRAPHIX ADVANTAGE
.
If you intend to operate the
HS15
plus
with software other than the
GRAPHIX ADVANTAGE
,
please contact your software vendor for an HS15
plus
plotter driver
and installation instructions specific to your software.
Assembling the Plotter
1. Carefully remove the HS15
plus
from its packaging materials and
place it near the
GRAPHIX ADVANTAGE
system. The cable is 10
feet long, so the plotter need not be located immediately beside the
console; however, it should be close enough so there will be no
strain on the cable after installation.
2. Remove the two screws for mounting the tool holder from the rear
of the plotter cover. Mount the tool rack at the rear of the plotter.
3. Place the material roll holder on the tension arm base and place the
material tension arm next to the HS15
plus
.
