ERROR CONDITIONS
The HS15
plus
is programmed to detect certain mechanical/electrical error
conditions at power-up or during operation. When an error condition
occurs, the plotter may turn off power to the servo motors. There will be
continuous beeping and flashing lights.
Error Signals
There are three kinds of error signals:
3-second steady tone, lights on (running job)
The plotter continues but the job is clipped (parts are not plotted).
This happens when the job has exceeded the boundaries of the
plotter. There is no recovery and the job must be sent again with a
starting position that allows the job to fit within the plotting area.
3-second steady tone, lights on (no running job, slewing only,
part of plotter jarred)
One or more axes are shut down because of excessive lag. For
recovery, press the RESET button to turn the axes on again. The Z,
theta, and Y axes will return to their home position. If a job was
pending, it must be resent.
Continuous beep and flashing lights
With this warning a procedure has been established to determine
which error condition may have occurred. See the next page for
determining error numbers.
